5052 H32 aluminium strip for hard disk

Henan chalco aluminum is manufactured with 5052 H32 aluminium strip for aluminium alloy hard disk. It has a good surface and is easy to oxidize. Early hard disk discs used plastic materials as the base, and then coated with magnetic materials on the plastic base to form hard disk discs. Later, with the increase of the speed and capacity of hard disk, the metal disk base has higher recording density, hardness and safety than the plastic disk base. At present, the mainstream hard drives in the market are metal disk base made of aluminium material. At present, most of the hard disk discs are made of aluminium alloy and have special coatings on the surface, because of its small deformation rate at high temperature.



5052 H32 aluminium strip for hard disk Specifications
Alloy：5052 H32
Thickness: 1.0-3.0 mm
Width: 200-1500
Inner diameter: 500mm
Outside diameter: 1500mm max

5052 H32 aluminium strip for hard disk Mechanical properties

Tensile Strength Rm(Mpa):216~218
Yield Strength Rp 0.2 (Mpa): 167-171
Elongation%:12%~14%


5052 H32 aluminium strip for hard disk chemical composition：



化学成分CHEMICAL COMPOSITION（%）
Alloy:5052
Element	Si	Fe	Cu	Mn	Mg	Zn	Ti	Cr	Other		Al
									Each	Total
Actual	0.25	0.21	0.4	0.1	2.2~2.8	0.1	-	-	≤0.05	≤0.15	Rem
